Sheet goods are securely supported at all times during machining by the STM 1800's many support points.
Video
360°
Illustrations are examples. Please note the variant and scope of delivery.
STM 1800
Mobile saw table and work bench
Contains
2 Article
Product details
Functions
Mobile Saw Table and Work Bench
Ideal for cutting sheet goods and/or using as an assembly bench on construction sites, production shop, or the home workshop: designed to be operated by one person, saving both time and money during your fabrication and assembly process.
- Ideal for use on the go thanks to compact dimensions (when collapsed for transport), low weight, and robust chassis
- Intuitive design promotes easy setup and use
- Footprint is adjustable for working environment and material sizes
- Height adjustable from 27-5/8” (700 mm) to 35-7/16” (900 mm) / 5 positions at 2” (50 mm) increments
- Robust locking casters for stability and ease of mobility
- 71” x 71” (1800 mm x 1800 mm) support area with renewable table supports
- height-adjustable work bench for machining large panels and cutting them to size
- contact surface can be extended using extension tubes
- castor wheels and wooden supports partially pre-installed (items included)
Technical data
Specifications
Weight
74.00 lbs (34 kg)
Max. contact surface
70-7/8" x 82-11/16" (1800 x 2100 mm)
Min. contact surface
43-1/4" x 41-3/8" (1100 x 1050 mm)
Max. load
329 lbs (150.00 kg)
Height adjustable
27-9/16" to 35-7/16" (700 - 900 mm)
Table dimensions (LxWxH) when folded
45-1/4" x 9-7/8" x 27-9/16" (1150 x 250 x 700 mm)
max. workpiece dimensions (with tilting function)
10'-2"x 7'-5/8" (3100 x 2150 mm)
Downloads
Highlights
The perfect accessories for your craft
Safe working conditions
Can be operated by one person
Even the largest sheet material of up to 10'x7' can be supported and machined by a single person.
Mobile panel saw
In conjunction with the portable track saw and guide rail, the saw table and workbench turn into a mobile panel saw system.
